These signs can be placed below traffic and direction signs. Subpanels with blue background are combined with signs that have blue background, and subpanels with white background with signs that have white background. The signs can for instance be used below parking restriction signs to indicate which time of day, what day(s) of the week or the duration of parking for which the restriction applies,
U1.1: Distance (here in 500 meters)
U1.2: Distance (here in 500 meters)
U2.1: Distance interval (here from 200 to 800 meters)
U2.2: Distance interval (here from 200 to 800 meters)
U3.1: Length of time (here 1 hour)
U3.2: Day of week (here Wednesday)
U3.3: Time of day on weekdays. If in parentheses, Saturdays, if in red, Sundays or holidays. (here from 8 AM to 5 PM weekdays, from 8 AM to 2 PM Saturdays and from 9 AM to 12 AM on Sundays or holidays
U3.4:: Length of time (here 1 hour)
U3.5: Day of week (here Wednesday)
U3.6: Time of day on weekdays. If in parentheses, Saturdays, if in red, Sundays or holidays. (here from 8 AM to 5 PM weekdays, from 8 AM to 2 PM Saturdays and from 9 AM to 12 AM on Sundays or holidays
U4.1: Type(s) of vehicle (here heavy goods vehicle)
U4.2: Type(s) of vehicle (here heavy goods vehicle)
U5.1: Bicycles and small mopeds exempt
U5.2: Bicycles and small mopeds exempt
U6.3: A sign combination this panel is a part of, takes effect after a right turn in the intersection ahead
U6.4: A sign combination this panel is a part of, takes effect after a right turn in the intersection ahead
U7: Bicycles and small mopeds may make right turn when traffic signal is red.
Symbols
A 70 km/h speed limit sign which applies only to the vehicles displayed in the subpanel.
US1: Car (not above 3.5 ton registered weight)
US2: Heavy goods vehicle with or without a trailer
US3: Bus (above 3.5 ton registered weight, or is allowed to carry more than 8 passengers)
US4: Heavy goods vehicle with trailer
US5: Trailer
US6: Caravan
US7: Motorhome
US8: Bicycle or small moped
US9:Small moped
US10: Motorcycle or large moped
US11: Tractor or motorized equipment
US12: Disabled
US13: Light rail
Historic signs
A21: Cyclists
A22: Children
Slippery road
A99: Other danger
B13: Stop
C12: No U-turn
Goods vehicles prohibited
C51: No overtaking
D21: Cycleway
D22: Footway
D27: Combined path
E17: Pedestrian crossing
E33.1: Parking
1932 road signs
Danger
Uneven road
Series of bends
Crossroad
Level crossing with barriers
Level crossing without barriers
No motor vehicles
Do not enter
No parking
Mandatory direction
Pedestrian crossing
Roundabout
Parking
Weight limit
Speed limit
Yield
Priority road
Priority road ends
First aid
Notes
↑ Built-up areas (urban areas), are in this context areas within the signs for entering and leaving a built-up area. and
↑These signs are placed at a different distance than the other warning signs: A18: Two-way traffic A35: Dangerous shoulder A74: Level crossing A75: Distance to level crossing A92: Quayside The distance at which these signs are placed, is found in the description of the signs in §12 of executive order 425 from 2023[2]
↑Experimental sign. An actibump is a method of traffic calming. It is being tested in two places in Denmark.[6][7]
↑Used at the beginning of a 2-1 road in combination with A43.1
↑The bicycle symbol also applies to a class of vehicles called small mopeds (50cc and restricted to max 30 km/h)
↑The speed limit is in force until it is lifted by the sign "C59 end of local speed limit", "C59 End of prohibition", another local speed limit sign or after a distance indicated on a subpanel. (The built up area sign is also a speed limit sign)
↑This diagram consists of two signs: the upper part indicates the speed limits, and the lower part indicates that it is mandatory to use seat belts and headlights.
12The sign is placed above a lane before a split in the motorway, or before an exit. The signs can contain additional information as well as arrow(s) pointing down to the lane(s)
↑The permission to do this is found in §359 ¶2 in Executive Order 426 from 2023.[3]
